제품 상세 정보:
|
SC to SC Fiber Optic Patch Cable – Duplex Jumper Cord for Singlemode or Multimode Applications in FTTx, Data Center, Telecom
Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | SC to SC Fiber Optic Patch Cord |
| Connector Type | SC/UPC or SC/APC to SC/UPC or SC/APC |
| Fiber Type | Singlemode (OS2) / Multimode (OM1/OM2/OM3/OM4) |
| Cable Structure | Simplex / Duplex |
| Jacket Material | PVC / LSZH / OFNR |
| Insertion Loss | ≤0.3dB (Typical ≤0.2dB) |
| Return Loss | ≥50dB (UPC) / ≥60dB (APC) |
| Cable Diameter | 2.0mm / 3.0mm |
| Length Options | 0.5m / 1m / 2m / 3m / 5m / 10m / Custom |
| Operating Temperature | -20°C to +70°C |
| Jacket Color | Yellow (SM), Orange/Aqua/Violet (MM) |
| Polish Type | UPC / APC |
The SC to SC Fiber Optic Patch Cable is designed for high-precision optical signal transmission in data centers, telecom networks, and FTTx deployments. It features SC connectors on both ends with UPC or APC polish options, providing reliable, low-loss connectivity.
With options in singlemode and multimode, and support for simplex or duplex, it is suitable for a wide range of network topologies and device interfaces.
Connector Type: SC to SC (UPC or APC polish)
Cable Mode: Singlemode (OS2) or Multimode (OM1–OM4)
Structure: Simplex or Duplex
Lengths: From 0.5 meters to 50 meters (custom available)
Temperature: -20°C to +70°C
Jacket Material: PVC / LSZH / OFNR
| Fiber Mode | Jacket Color | Polish Options | Application Range |
|---|---|---|---|
| OS2 | Yellow | UPC/APC | Long-distance telecom, FTTx |
| OM1/OM2 | Orange | UPC | Short-range enterprise networks |
| OM3 | Aqua | UPC | 10G backbone and SAN |
| OM4 | Violet / Aqua | UPC | 40G/100G high-density networks |
Diameter: 2.0mm or 3.0mm
Structure: Simplex / Duplex
Low insertion loss and high return loss for reliable performance
Flame-retardant cable jacket for indoor cabling
High-density SC connectors for easy installation
Compatible with telecom and enterprise networking hardware
Color-coded jacket for quick mode identification
FTTx networks (FTTH, FTTB, FTTO)
Telecom base stations and switch cabinets
Data center server interconnections
Optical distribution frames (ODF)
Enterprise LAN and SAN systems
Optical media converters and routers
Clean connectors with fiber cleaning tools before connection
Avoid excessive bending (follow minimum bend radius)
Use dust caps when cables are not in use
Store in dry, temperature-controlled environments
