제품 상세 정보:
|
| Type: | 54W Laptop Charger | DC: | DC 5.2*2.1MM/2.5MM |
|---|---|---|---|
| DC Cable: | 1M | Voltage: | 24V |
| Current: | 2.25A | Ouyput: | 54W |
| Certificates: | CE;FCC | ||
| 강조하다: | 24V laptop charger with 2.1MM DC,54W power supply adapter,2.25A laptop charger with warranty |
||
| Attribute | Value |
|---|---|
| Type | 54W Laptop Charger |
| DC | DC 5.2*2.1MM/2.5MM |
| DC Cable | 1M |
| Voltage | 24V |
| Current | 2.25A |
| Output | 54W |
| Certificates | CE; FCC |
| INPUT/OUTPUT SPECIFICATIONS: | |
| Input Voltage: | AC 100V-240V, 50/60Hz |
| Range Voltage: | AC 90V-264V, 47/63Hz |
| Output Voltage: | 12V-54V |
| Output Current: | 0.5A-5A |
| Over Current Protection: | 120% Min |
| Over Voltage Protection: | 150% Min |
| Short Protection: | Auto Recovery |
| Load Regulation: | ±5% |
| GENERAL SPECIFICATIONS: | |
| Operating Temperature: | 0 ~ 40°C |
| Operating Relative Humidity: | 5 ~ 95%RH |
| Storage Temperature: | -20 ~ 85 °C |
| Withstanding Voltage: | AC 3000V/Min (between Input & Output), 10mA(Max.) |
| Insulation Resistance: | DC500V 100MΩ(Min.) (between Input & Output) |
| Efficiency: | 70% Min |
| Size: | 52*41*25mm (L*W*H) |
| Safety: | CE |
