3 Pin EU Schuko Plug to Stripped End Power Cord 250V

3 Pin EU Schuko Plug to Stripped End Power Cord 250V
3 Pin EU Schuko Plug to Stripped End Power Cord 250V 3 Pin EU Schuko Plug to Stripped End Power Cord 250V 3 Pin EU Schuko Plug to Stripped End Power Cord 250V 3 Pin EU Schuko Plug to Stripped End Power Cord 250V

큰 이미지 :  3 Pin EU Schuko Plug to Stripped End Power Cord 250V

제품 상세 정보:
원래 장소: Dongguan
브랜드 이름: KUNCAN
인증: VDE
결제 및 배송 조건:
최소 주문 수량: 2pcs
가격: 0.92USD/PCS
포장 세부 사항: PE 백
배달 시간: 25 일
지불 조건: l/c, d/a, d/p, t/t
공급 능력: 일주일에 3000pcs

3 Pin EU Schuko Plug to Stripped End Power Cord 250V

설명
유형: EU는 끝 전원 코드를 벗겨 냈습니다 핀: 3개 핀
케이블 게이지: H05 VVF 3*0.75mm/1.0mm/1.5mm 플러그 표준: 베어 엔드
입력: 250V 용법: 실내
사용: 컴퓨터, 노트북과 같은 가정 기기 재킷: PVC
재료: 구리
강조하다:

3 pin Schuko plug power cord

,

EU power cord with stripped ends

,

250V Schuko plug power cable

3Pin End Stripped Bare Wires Ac Open Wiring With European Schuko Plug Power Cord Black
Product Specifications
Type EU to Stripped End Power Cord
Pin 3 Pin
Cable Gauges H05 VVF 3*0.75mm/1.0mm/1.5mm
Plug Standard Bare End
Input 250V
Usage Indoor
Using For Home appliance, like computer, laptop
Jacket PVC
Material Copper
Product Images
Technical Specifications
  • Plug Type: CEE 7/7 (German Schuko/French hybrid)
  • Voltage Rating: 250V AC
  • Current Rating: 16A
  • Conductor Size: 3 x 1.5mm² (16A) or 3 x 2.5mm² (25A)
  • Cable Construction: 3-core stranded copper with PVC insulation
  • Cable Outer Diameter: Approximately 7.5mm
  • Jacket Material: Flexible PVC (black)
  • Temperature Range: -30°C to +70°C
  • Standard Compliance: EN 50525 / HD 21.5
Key Product Features
  • Professional-Grade Construction: High-conductivity copper conductors with thick PVC insulation. Durable outer jacket resistant to abrasions and chemicals.
  • Versatile Termination Options: Stripped and tinned conductor ends for secure connections. Suitable for screw terminals, terminal blocks, or soldering.
  • Safety Assurance: Double insulation design for operator protection. Meets European electrical safety directives.
  • Professional Applications: Perfect for equipment requiring hard-wired power connections. Commonly used by electricians and technicians.
Recommended Usage Scenarios
  • Permanent installation of industrial equipment
  • Replacement power cord for professional appliances
  • Workshop installations and machinery wiring
  • Audio/video and stage lighting installations
  • Custom electrical projects requiring secure connections
Connection Guidelines
  • Always disconnect from power source before installation
  • Match conductor colors to appropriate terminals: Brown (Live), Blue (Neutral), Green/Yellow (Ground)
  • Use proper cable clamps for strain relief
  • Verify all connections are tight and secure
Safety Compliance Information
  • Complies with European Low Voltage Directive
  • Meets harmonized standards for power cables
  • RoHS compliant for environmental safety
Quality Assurance

Manufactured to exacting industry standards for professional use. The high-quality copper conductors ensure minimal power loss and reliable performance in demanding environments.

Frequently Asked Questions
Q1. Are you factory or trade company?

A: We are factory of more than 16 years export experience.

Q2. What is your terms of payment?

A: T/T 30% as deposit, and 70% before delivery.

Q3. What is your terms of delivery?

A: EXW, FOB, CFR, CIF, DDU.

Q4. Samples?

A: 2-5 pieces free samples are available, freight on you. Delivery time usually is 2-3 days. Customized samples will take 5-10 days.

Q5. What is delivery time if we place an order?

A: It depends order quantities. Usually, we can deliver goods within 10-15 working days, for more QTY order, let's confirm when you place official order.

Q6. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.

Q7: How to ship out the cargo?

A: At your request, by sea, by express, all are available.
